Across Bridge Pump
Across Bridge Pump
It is applied to the well with long tail pipe or the well installed with sealer or deviated well.
Non API Standard Subsurface Pump 1.GB/T18607-2008; 2.Anti-Corrosion; 3.Wear-resisting; 4.Hard-Chromium plated.
The special subsurface pump has the advantages of reasonable design, high efficiency of sucking oil, anti-corrosion and wear-resisting
Technical Feature:
* The pump barrel is made of high quality special-purpose pipe. The internal surface is processed by surface strengthening of chrome plating or the nickel phosphorus compound plating and so on, to achieve good intensity and rigidity, wear-resistance and anticorrosion property.
* The plunger surface is processed by spray metal coated of nickel base alloy powder to achieve good wear resistance and anti-corrosion property.
* The pump efficiency is high and pump workover is long.
Speciifcation
Type
Code
Pump Bore
Plunger Length
Barrel Length
Tubing OD
Sucker Rod Diameter
Tubing Pump
20/25-106TH
28.5
0.6-2.1
3.3-9.5
60.3-73.0
15.9-19.1
20/25-125TH
31.8
0.6-2.1
3.3-9.5
60.3-73.0
15.9-19.1
20/25-150TH
38.1
0.6-2.1
3.3-9.5
60.3-73.0
19.1
20/25-175TH
44.5
0.6-2.1
3.3-9.5
60.3-73.0
19.1
25-200TH
50.8
0.6-2.1
3.3-9.5
73
19.1
25-225TH
57.2
0.6-2.1
3.3-9.5
73
19.1
30-275TH
69.9
0.6-2.1
3.3-9.5
88.9
22.2
40-375TH
95.3
0.6-2.1
3.3-9.5
114.3
25.4
Rod Pump
20-125RH/RW
31.8
0.6-2.1
3.3-9.5
60.3
19.1
20/25-150RH/RW
38.1
0.6-2.1
3.3-9.5
60.3-73.0
19.1
25-175RH/RW
44.5
0.6-2.1
3.3-9.5
73
19.1
25-200RW
50.8
0.6-2.1
3.3-9.5
73
19.1
30-225RH/RW
57.2
0.6-2.1
3.3-9.5
88.9
19.1
Long plunger anti-sand pump
20/25-125-225TH
31.8-57.2
3.3-6.3
1.2-2.1
60.3-73.0
19.1-12.2
Across bridge Pump
25/30-150-225TH
31.8-57.2
0.6-2.1
3.3-9.5
73.0-88.9
19.1-22.2
Slim Hole Pump
20-125-175TH
31.8-44.5
0.6-2.1
3.3-9.5
60.3
190.1
Long plunger anti-salt pump
25-125-225TH
31.8-57.2
3.3-6.3
1.2-2.1
73
19.1-22.2
Anti-gas pump
25-125-225TH
31.8-57.2
1.2-2.1
3.3-9.5
73
19.1
25-150/225TH
31.8-57.2
1.2-6.3
3.3-9.5
73
19.1
25-175/225TH
44.5-57.2
1.2-6.3
3.3-6.6
73
19.1
Deviated well
Pump
25-150-225TH
31.8-57.2
0.6-2.1
3.3-9.5
73
19.1
(mm)
(m)
(m)
(mm)
(mm)
